Section 3.0
MAN 06–0017H ZIEHM QUANTUM User’s Manual Page 35 of 220
The laser targeting device is a Class 2 laser product according to IEC 60825-1:2001 and CLASS
II, in accordance with FDA 21 CFR, Subchapter J, Section 1040.10 - you must comply with all
operating precautions when operating the laser device.
The maximum output of continuous laser radiation, measured at the beam exit, is <1 mW. The
wavelength of the emitted radiation is 635 nm.
WARNING
LASER RADIATION – DO NOT LOOK INTO THE BEAM!
Please observe the provisions of IEC 60825-1:2001, Section 3 and 21CFR
1040.10-11. Guidelines for the User of the laser devices.
3.6.2 MAINTENANCE
The laser targeting device is maintenance-free. Any adjustment or repair which might become
necessary must be carried out be the manuafacturer or a person who has been authorized to do so
by the manuafacturer.
Figure 3.1: Laser Beam Aperture on the Image Intensifier (left) and on the Generator (right)
3.6.3 LASER RADIATION
The laser alignment device incorporates the use of diode laser modules that emit laser radiation.
Do not, under any circumstances, look directly at the laser beam or any scattered laser radiation
-either with naked eyes or with optical instruments.
WARNING:
LASER RADIATION DO NOT LOOK INTO THE BEAM! LASER
CLASS II, IN ACCORDANCE WITH FDA 21 CFR, Subchapter J, Section
1040.10 - 11 and EN60825 - 1:1994.
You must comply with all operating safety precautions when operating the laser device. The
maximum output of continuous laser radiation, measured at the laser beam exit is <1 mW. The
