Section 9.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 131 of 220
The CINE Button will be highlighted on the DeskView screen and the selected frame rate
will be display on the touch screen.
3. Press and hold the hand or foot switch. The left monitor will display the message
“INJECT” in the lower center of the screen to indicate that the system has started capture of
images.
4. Start the injection of contrast media.
5. Continuing holding the exposure switch until the desired vascular anatomy has been
visualized.
6. The acquired images will begin to play back in a continuous loop from the hard drive or
from memory, depending on frame rate selected and the system’s optional equipment.
9.7.1. ACQUIRING A NEW CINE RUN
If scout fluoroscopy is necessary between runs, press the CINE button to exit and return to
normal fluoroscopy.
Repeat the Cine procedure above. To acquire another study /cine run
9.7.2. IMAGE STEP
During CINE replay, image playback can be stopped and individual
images can be reviewed and or stored to the patient file.
1. Press one of the Contrast buttons on the Mobile Stand Control Panel or the Arrow
playback buttons on the DeskView Control Panel. This places the system into a playback
mode that steps through images one at-a-time.
1) The message “F/R OFF” will display in the upper right corner of the monitor,
indicating that the image loop has stopped and that the operator can now step
through the images.
Press either button to step through the images. Hold down either button to step
through the images at nearly the selected frame rate.
2) When image playback has stopped, select the image to transfer to the patient file
and press either of the Image Store buttons.
3) The message “Stored to XXXX” is displayed on the left monitor which indicates
that the image has been copied to the patient file as image number XXXX.
