Ziehm Imaging, Inc. QUANTUM User Manual

Section 5.0
MAN 06–0017H ZIEHM QUANTUM User’s Manual Page 55 of 220
5.3.2 ANGULATION
The C-arm can be rotated by ± 225° in the vertical plane around the horizontal axis (i.e., the
horizontal carriage). A scale with 10° divisions is provided at the pivot joint of the horizontal
carriage to facilitate precise positioning.
Fig 5.5 Angulation of the C-Arm
NOTE
Rotation Brake for angulations is on the horizontal arm of the Mobile stand See
Fig 5.1
5.3.3 SWIVELING (PANNING)
The C-arm can be swiveled 10° to the left or to the right around the vertical axis of the lifting
column.
