Ziehm Imaging, Inc. QUANTUM User Manual

Section 7.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 94 of 220
7.15 SCREEN DISPLAY DURING RADIATION
7.15.1 FLUOROSCOPIC
While radiation is active, the current fluoroscopic image is displayed on the
live monitor screen and the DeskView touch screen. See Fig 7.2.
When you terminate radiation (by releasing the hand or foot switch), the last
fluoroscopic image is displayed on the live monitor and the DeskView touch
screen (Last Image Hold).
This image remains displayed until it is replaced by a new fluoroscopic image
or a reference image is transferred to the live monitor display. See Fig 7.2.
7.15.2 FLUOROSCOPY FACTORS
During the exposure, the tube voltage and the tube current are determined by system, and the
technique values are shown on the displays for Voltage and Current, Fluoroscopy time, and
AKR (dose) in the upper left corner of Fig 7.2.
During the exposure (fluoroscopy or direct radiography), the yellow radiation Warning Lamp on
the monitor assembly and the X-ray Symbol on the DeskView control panel are illuminated. See
Fig 7.2.
NOTE:
AKR dose display is not active and is not displayed on systems manufactured before
June 2006.
