Section 10.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 146 of 220
A complete CD-R with 600MB of data can take more than 30 minutes.
A complete DVD-R with 4.0GB of data can take greater than 1 hour
The Export functions are located on a single screen and can be accessed from the patient
File screen.
The USB and DVD buttons on the Archive screen will not be displayed if the user is not
logged into the system.
10.10.2 ENTER ARCHIVE
To enter the ARCHIVE screen to export patient records/images the operator must first Log In
into the system using one of the assigned permissions.
The user/operator must then select the FILE button from the main touch screen.
Once the patient file screen is open the user must select a patient that has images attached to its
file by pressing one of the patients listed on the screen.
Now press the PRE_SELECT/ADD TO LIST button to select the patient to make active the
ARCHIVE button on the screen.
At least one patient file must be selected/added to the list before the archive button will be active.
Once you have selected all the patients for the Archive list, now press the ARCHIVE button, the
user/operator is presented with the Archive screen See Fig 10.5 below.
Note: the system will update the Display Monitors with the last four images of the patient file to
confirm the patient file and images. This may take 2 to 3seonds for the update between selections
on the Patient file screen.
