Section 12.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 183 of 220
Image intensifier
Nominal sizes:
23 / 17 / opt (10) cm
Anti-scatter grid
Pb 8/40
C-arm
Source–image receptor distance: 970 mm
Source-image receptor Opt 31: 1007mm
Vertical free space: 750 mm
Vertical free space: 787.4mm
Immersion depth: 680 mm
Dimensions
Orbital rotation: 135° a
Angulation: ± 225°
Swiveling (panning): ±10°
Horizontal movement: 220 mm
Vertical movement: 430 mm
C-arm stand
With 23 cm I.I.: approx. 260 kg
Environmental
During Storage
conditions
Temperature: -10°C to +60°C
Relative air humidity: 10% - 95% non Condensing max.
During operation
Environmental
Temperature: +10°C to +35°C
Relative air humidity: 35%-75% non Condensing max.
12.3 X-RAY GENERATOR X-RAY GENERATOR, HOUSING AND TUBE WITH BEAM-
LIMITING DEVICE
Device: ZIEHM QUANTUM C-Arm with x-ray source assembly Maxipuls 3-110 Generator
Manufacturer: Ziehm GmbH
ZIEHM Maxipuls 3-110
- Total filtration > 4 mm AL
- Focal spot 06./1.5 mm or 0.5 /1.5mm
- Tube type Nagel & Goller
EP-F 181-0.6/1.5 - 125-60
- Tube type Toshiba DF-151-R-0.5/1.5-110-40
- Registration no. BY 287/84/RO
- Target material Tungsten
- Target angle 12º
- Radiation leakage < 1 m Sv/h at 110 kV/7200 mAs/ hr
- Maximum admissible high voltage 110 kV
