Section 10.0
MAN 06–0017H
ZIEHM QUANTUM User’s Manual Page 155 of 220
the DICOM store or Print button.
NOTE:
In all cases with DICOM the system must have prior programming and settings made to
identify and provide correct addresses for the DICOM network server and printer.
10.11 PATIENT FOLDERS:
The ZIEHM QUANTUM will create on the USB and DVD files folders for the images exported
to the devices. The Patient folders made by the archive /export function on both the DVD and
USB memory Peripheral are made in a file tree structure. The actual folders stored on the disk or
USB device will be similar to the example below.
Within each folder the individual images are listed and can be identified by Name ID and Date of
creation. The following is just an example not to infer actual patient information.
Fig 10.8: Example of typical file naming structure
(Following folders DO NOT represent real patient information)
