Section 2.0
MAN 06–0017H ZIEHM QUANTUM User’s Manual Page 18 of 220
2.2.6 IMAGE MANAGEMENT
A patient-based image management system providing an image Mosaic (thumbnails) view and
menu-controlled user guidance guaranties efficient image data handling.
2.2.7 DOCUMENTATION AND OUTPUT
For documentation purposes, optional USB image port is available, as well as an optional DVD
re-writer allowing film less archiving in PC compatible full resolution digital BMP image format.
You also have the option to save your images in DICOM format and/or other optional image
formats depending on system configurations. Patient-related data, data (e.g. the fluoroscopy
parameters) are included in the stored image. In addition, all systems have a video BNC output.
2.2.8 NETWORKABILITY
The optional DICOM 3.0 interface (Quantum FlexNet) enables integration into any network
supporting DICOM 3.0, e.g. PACS. Thanks to “Primary Capture” support, the original
fluoroscopic images can be archived without changes to the image that may have been applied to
them later. The following DICOM Classes are available:
- Storage
- Work list
- Print
WARNING
Do not touch the USB or DICOM ports and the patient at the same time. Failure to
observe this warning may result in serious injury to patient or operator.
WARNING
Accessory equipment connected to the analog and digital interfaces must be
certified to the respective IEC standards (i.e. IEC 60950 for data processing
equipment and IEC 60601-1 for medical equipment.) Furthermore, all
configurations shall comply with the system standard IEC 60601-1-1.
Everybody who connects additional equipment to the signal input part or signal
output part configures a medical system, and is therefore responsible that the system
complies with the requirements of IEC 60601-1-1. If in doubt, consult the technical
services department of your local representative.
2.3 OPTIONS
This manual describes a system with maximum configuration. The system configuration chosen
by you may not contain all options and functions described here.
The following options can be integrated into the system upon request:
- The DICOM 3.0 interface ZIEHM QUANTUM FlexNet (Primary Capture)
Depending on the system configuration chosen, the following functions, features and
DICOM Classes are supported:
