Vehicle preparation
•
Rest the vehicle on its stand
•
Support the vehicle rear part using belts and hoist.
•
Drain off the cooling system.
•
Beforehand, remove the lug, the side fairings, the battery, the fuel tank, the side fairings,
the drive chain, the air filter box, the radiator and the expansion tank.
•
Position an under-sump stand that will be supported on the lower side of the engine.
Removing the engine from the vehicle
•
Prepare the vehicle as described.
•
Disconnect the quick coupler.
•
Loosen the clutch adjuster screw.
•
Unhook the clutch cable and free it
from the cable grommet.
•
Undo and remove the screw and dis-
connect the starter ground cable.
RS 125 - Tuono 125 - Euro 4 Engine from vehicle
ENG VE - 153
