km (mi) x1000 1 (0.6) 6 (3.7) 12 (7.5) 18 (11.2) 24 (14.9) 30 (18.6) 36 (22.4) 42 (26.1) 48 (29.8)
Fuel and oil pipes + filters
(3)
I I R I I R I I R
Brake pipes I I I I I I I I
Labour time (minutes) 50 130 80 150 80 240 170 130 80
NOTE
AT EACH SCHEDULED MAINTENANCE MUST BE VERIFIED WITH THE DIAGNOSTIC TOOL IF
THERE ARE ERRORS AND THE IF THE PARAMETERS ARE CORRECT.
Recommended products
Piaggio Group recommends the products of its
"Castrol Official Partner" for the scheduled
maintenance of its vehicles.
Use lubricants and liquids having specifications
that are equivalent, or superior, to the recommen-
ded products. These indications also apply when
topping up fluid levels.
RECOMMENDED PRODUCTS TABLE
Product Description Specifications
Engine oil 5W -40 Synthetic-based lubricant for four-stroke
engines.
SAE 5W-40; JASO MA, MA2; API SL;
ACEA A3
Anti-freeze liquid, ready to use, colour red Ethylene glycol antifreeze liquid with or-
ganic inhibition additives. Red, ready to
use.
ASTM D 3306 - ASTM D 4656 - ASTM D
4985 - CUNA NC 956-16
Brake fluid DOT 4 Synthetic brake fluid. SAE J 1703; FMVSS 116; ISO 4925; CU-
NA NC 956 DOT4
Lithium-based grease Lithium-calcium soap based grease colour - black, contains EP (Extreme
Pressure) additives, excellent water-re-
pellent properties
Vaseline neutral grease for battery terminals -
Spray grease for chains Spray lubricant grease -
Fork oil 7.5W Fork oil. SAE 7.5W
Spark plug
•
Lift the tank.
•
Disconnect the spark plug H.V. cable
boot and remove the spark plug.
•
Check the condition of the spark plug,
check that the insulating material is un-
damaged and measure the gap be-
tween the electrodes with a feeler
gauge.
•
If necessary, adjust the gap by bending
the side electrode very carefully.
Maintenance RS 125 - Tuono 125 - Euro 4
MAIN - 66
