Remove the spring.
•
Unscrew and remove the two screws
(6) and remove the entire tensioner
control.
•
Lock the timing gear using the specific
tool.
Specific tooling
865260 Camshaft sprocket lock tool
•
Unscrew and remove the gear.
•
Repeat the operation with the other
gear.
Cylinder head
Engine RS 125 - Tuono 125 - Euro 4
ENG - 202
