REAR MUDGUARD
Pos. Description Type Quantity Torque Notes
1 Screw fastening rear mudguard to
swingarm
Self-tapping
M4.8x12
4 3 Nm (2.21 lb ft) -
ELECTRICAL COMPONENTS
Pos. Description Type Quantity Torque Notes
1 Screw fixing coil to mounting M8 2 20 Nm (14.75 lb ft) -
2 Screw fixing coil to mounting M6x12 1 10 Nm (7.38 lb ft) -
Characteristics RS 125 - Tuono 125 - Euro 4
CHAR - 44
