APRILIA Tuono 125 Euro 4 User Manual

•
The measurement must be carried out at the indicated point.
CAUTION
LIFT THE FRONT WHEEL AT THE END OF THE OPERATION AND CHECK THAT IT SPINS FREE-
LY WITH THE BRAKE LEVER IN REST POSITION.
CHECK THAT THE BRAKE LEVER HAS FREE STROKE WITHIN THE LIMITS PRESCRIBED IN
THE ASSEMBLY PHASE.
IF THE BRAKE LEVER DOES NOT HAVE ANY CLEARANCE, THIS COULD CAUSE FAILURE OR
LOCKING OF THE FRONT BRAKE, DUE TO OVERHEATING OF THE DISC AND THE BRAKE
CALLIPER.
ONCE YOU HAVE FINISHED AND AFTER CHECKING THE CONTROLS, IT IS NECESSARY TO
LEAVE THE BRAKE THREAD SEALANT TO CURE.
ONLY USE THE VEHICLE ONCE THE BRAKE THREAD SEALANT HAS CURED.
Rear brake pump
Rimozione
(RS 125)
•
Remove the screws, disconnect the
pipe and collect the brake fluid in a
suitable receptacle.
Braking system RS 125 - Tuono 125 - Euro 4
BRAK SYS - 306
