TABLE I2
1. Main wiring harness.
2. Cable guide.
CAUTION
PLACE THE GREY REFERENCE MARKS ON THE WIRING
HARNESS IN THE RESPECTIVE CABLE FASTENERS AND
CLOSE THEM, POSITIONING THE WIRING HARNESS AS
SHOWN IN THE PHOTOGRAPH.
TABLE I3
1. Secondary fuses.
2. Main fuses.
3. Main fuse.
Electrical system RS 125 - Tuono 125 - Euro 4
ELE SYS - 92
