TIMING SYSTEM
pos. Description Type Quantity Torque Notes
1 Chain tensioner pad fastener screw M6x16 1 10 Nm (7.38 lb ft) Loctite 243
2 Timing system gear fastener screw M8x40 2 27 Nm (19.91 lb ft) Loctite 243
Removing the head cover
•
Remove the adjuster screw covers (1).
•
Unscrew and remove the four cylinder
head screws (2).
•
Remove the cylinder head (3).
•
Remove the gasket (4).
Engine RS 125 - Tuono 125 - Euro 4
ENG - 200
