4. Injector
5. Battery
6. Main fuses
7. Fan relay
8. Light relay
9. Headlight unit
10.Starter relay
11.Electric fan.
12.Lambda probe
13.Fuel reserve sensor
14.Oil pressure sensor
15.Coil
16.Fuel pump
17.Injection relay
18.Secondary fuses
19.Instrument panel
20.Flasher unit
21.Regulator
22.Front ABS sensor
23.Spark plug boot
24.Temperature sensor
25.Starter motor
26.Neutral sensor
27.Stand sensor
28.MIU G3 control unit
Electrical system installation
Scope and applicability
This document defines the position of the vehicle wiring harness, how it is routed and fixed to the
chassis, instrument holder arch brace and saddle post, any problems and special checks to be made
on the cable connections and routing in order to achieve vehicle reliability.
Materials used and corresponding quantities
The electrical system consists of the following wiring harnesses and parts:
•
1 main wiring harness
•
1 headlight wiring harness
•
1 license plate holder wiring harness
•
1 chassis - engine ground cable
RS 125 - Tuono 125 - Euro 4 Electrical system
ELE SYS - 77
