Place the gear paying attention that the
operation is oriented to the cover;
•
Use the specific tool "B" as an endstop
in order to push the gear, with the
press, until it is in line with the shaft.
Specific tooling
866380 tool description
•
Place the sealing ring and push it until
it stops with the specific tool "C" by us-
ing the press.
Specific tooling
866380 tool description
•
Install the clutch cover;
•
Install the rotor and the water pump
cover.
Removing the radiator
•
Remove the expansion tank and the
radiator cowl.
•
Unscrew the screw and loosen the ra-
diator hose fastening clamp.
Cooling system RS 125 - Tuono 125 - Euro 4
COOL SYS - 316
