Taillight assy.
•
First remove the tail fairing and the
passenger seat.
•
Remove the two side screws (1).
•
Remove the two top screws (2).
•
Disconnect the connector.
•
Take off the rear light unit, by removing
it from the hooks.
Footrest
PASSENGER FOOTREST
The following procedures only refer to one foot-
rest, but they are applicable to both.
•
Remove the tail fairing.
•
Unscrew and remove the two fixing
screws.
•
Remove the passenger footrest.
See also
Bodywork RS 125 - Tuono 125 - Euro 4
BODYW - 348
