CYLINDER - PISTON
Pos. Description Type Quantity Torque Notes
1 Chain tensioner fastener screw M6x16 2 12 Nm (8.85 lb ft) -
THROTTLE BODY
Pos. Description Type Quantity Torque Notes
1 Sleeve fixing screw M6x20 3 12 Nm (8.85 lb ft) -
2 Sleeve fixing clamp - 1 0.8 Nm (0.59 lb ft) -
3 Injector mounting fixing screw M6x20 1 10 Nm (7.38 lb ft) -
Characteristics RS 125 - Tuono 125 - Euro 4
CHAR - 46
