Removing the starter motor
•
Undo and remove the two fixing screws
(1).
•
Remove the starter motor (2).
NOTE
THE STARTER MOTOR CAN ALSO BE REMOVED IF THE
ENGINE IS FITTED TO THE VEHICLE.
Generator side
FLYWHEEL COVER
pos. Description Type Quantity Torque Notes
1 Flywheel cover fastener screw M6 10 12 Nm (8.85 lb ft) -
2 Timing control cap M18 2 4 Nm (2.95 lb ft) -
3 Oil dipstick M12x1.5 1 5 Nm (3.69 lb ft) -
RS 125 - Tuono 125 - Euro 4 Engine
ENG - 175
