Drain the system as for the bleeding procedure, proceeding till reaching the indicated level
in the inspection glass.
•
Place the gasket and the cover and tighten the two fixing screws.
WARNING
IF THE BRAKE LEVER IS OPERATED WITH THE CLAMP EXTRACTED IT MIGHT BE NECESSARY
TO CARRY OUT THE CORRESPONDING BLEEDING.
Front brake pump
Removal
To remove the front brake pump, do not unscrew
the thrust screw on the brake lever as it is adjusted
and locked in the optimum position for the dead
stroke of the lever.
CAUTION
MODIFYING THE POSITION OF THE THRUST SCREW
COULD COMPROMISE THE CORRECT OPERATION OF
THE LEVER.
•
Unscrew and remove the screw. Dis-
connect the pipe to recover the brake
oil in the tank in a suitable container.
•
Unscrew and remove the two screws
fixing the U-bolt to the handlebar and
remove the front brake pump tank.
•
To reassemble, carry out the opera-
tions described in reverse order, tight-
ening the screws to the prescribed
torques.
Braking system RS 125 - Tuono 125 - Euro 4
BRAK SYS - 304
