DUCTS
pos. Description Type Quantity Torque Notes
1 Screw fastening upper ducts to lower
ones
Self tapping
screw, Ø 3.3
6 2 Nm (1.48 lb ft) -
2 Screws fastening ducts to chassis M6 2 6 Nm (4.43 lb ft) -
HANDLEBAR AND CONTROLS
pos. Description Type Quantity Torque Notes
1 Semi-handlebar fixing screw M8x30 2 25 Nm (18.44 lb ft) Loctite 243
2 Handlebar counterweight fastener
screw
M5x50 2 5 Nm (3.69 lb ft) Loctite 243
Characteristics RS 125 - Tuono 125 - Euro 4
CHAR - 22
