pos. Description Type Quantity Torque Notes
3 Camshaft cover fastener screw M6x40 4 11 Nm (8.11 lb ft) -
4 Head fastener screw M8x166 4 27 Nm + 90° (19.91 lb ft
+ 90°)
-
5 Thermostat cover fastener screw M6x20 2 11 Nm (8.11 lb ft) -
6 Head dowels retainer M8x10 2 6.5 Nm (4.79 lb ft) -
7 Thermostat retainer - 1 9 Nm (6.64 lb ft) -
IGNITION UNIT
pos. Description Type Quantity Torque Notes
1 Flywheel rotor fixing nut M14x1.5 1 86 Nm (63.43 lb ft) -
2 Rotor fastener screw - 6 12 Nm (8.85 lb ft) -
3 Stator clamping screws - 2 6 Nm (4.43 lb ft) -
4 Pick-Up clamping screw - 3 3.5 Nm (2.58 lb ft) -
Characteristics RS 125 - Tuono 125 - Euro 4
CHAR - 54
