Moving from the left side of the engine,
remove the flywheel and all of its com-
ponents beforehand.
•
Unscrew and remove the six screws on
the outside of the crankcase (1).
•
Unscrew and remove the longest
screw (2).
•
Unscrew and remove the five screws
(3).
•
Unscrew and remove the short screw
(4).
•
Remove the left crankcase.
Bearing removal
•
Heat the crankcase surface with a heat gun.
•
Remove the bearing using the specific extractor.
Engine RS 125 - Tuono 125 - Euro 4
ENG - 192
