APRILIA Tuono 125 Euro 4 User Manual

Tail guard
Side body panels
The following procedure is only shown from one
side of the vehicle, but it is valid for both side fair-
ings
•
Remove the saddle
•
Undo and remove the screw (1)
•
Undo and remove the screw (2)
•
Undo and remove the screw (3)
•
Remove the left side fairing
•
Repeat the entire procedure to remove
the right side fairing
Side fairings
(RS 125)
RS 125 - Tuono 125 - Euro 4 Bodywork
BODYW - 349

APRILIA Tuono 125 Euro 4 Specifications

General

Brand	APRILIA
Model	Tuono 125 Euro 4
Category	Motorcycle
Language	English
