Disassembling the clutch
•
Unscrew and remove the six screws by
loosening them 1/4 of a turn at a time;
operate in stages and diagonally, and
retrieve the washers and the clutch
springs.
•
Remove the thrust bearing.
•
Remove the discs.
•
Release the screw by lowering the lock
tab.
•
Block clutch bell rotation using the spe-
cific tool.
•
Unscrew and remove the clutch bell
fixing nut.
•
Remove the clutch hub.
Specific tooling
00H05300041 Clutch lock
Engine RS 125 - Tuono 125 - Euro 4
ENG - 182
