PIN 15 (Blue) - Hwvc 3 (-)
•
PIN 16 (Blue/Orange) - Wso_R
•
PIN 17 (Blue/Yellow) - ABS indicator light
•
PIN 18 (Red/White) - Battery positive for ABS pump motor
Operating diagram
Braking system RS 125 - Tuono 125 - Euro 4
BRAK SYS - 278
