The ABS system is disabled!
The system operates perfectly just as any other braking system without ABS.
The detection of malfunctions may require more or less time according to the type of failure.
Error detection logic foresees that for the errors to be diagnosed one or more conditions must persist
within a given time.
If during this given time one of the conditions is missing but then it comes back, the timer is reset and
the system is no longer able to diagnose the error.
The ABS system continues to be inactive.
ABS FAULTS - GUIDE TO THE DIAGNOSIS
1. ABS WARNING LIGHT ON
2. CONNECT DIAGNOSTICS INSTRUMENT
DOES THE DIAGNOSTICS INSTRUMENT COMMUNICATE? (NO, point 3; YES, point 4)
3.PERFORM THESE CHECKS:
•
A. Ground connection PIN 1
•
B. +12V at PIN 18
•
C. +12V live at PIN 4
4. ARE THERE ERRORS? (YES, point 5; NO, point 6)
5. CONSULT THE ERRORS TABLE
6. ABS WARNING LIGHT ACTIVATION
IS IT ACTIVATED? (YES, point 7; NO, point 8)
7. CONTACT TECHNICAL SERVICE
8. CHECK:
•
A. Cable continuity between PIN17 of the ABS control unit connector and PIN28 of the
instrument panel.
•
B. Check connectors - refer to the operations described in the chapter
If the previous checks are OK, the causes might be:
•
C. ABS control unit malfunction
•
D. Instrument panel malfunction
Use of diagnostics instrument for ABS system
Abs screen pages
Braking system RS 125 - Tuono 125 - Euro 4
BRAK SYS - 288
