Remove the water hose clamp (3).
•
Remove the cylinder (4).
•
Remove the gasket (5).
Disassembling the piston
•
Apply the tool under the piston (1).
•
Cover the base of the cylinder with a
cloth.
Specific tooling
865261 Piston retainer
•
Remove the retainer ring which locks
the pin (2).
Engine RS 125 - Tuono 125 - Euro 4
ENG - 212
