APRILIA Tuono 125 Euro 4 User Manual

Rear mudguard
•
Unscrew and remove the screw.
•
Slide off the pipe grommet.
•
Operating from the right side, unscrew
and remove the central screw.
•
Working on the left side, unscrew and
remove the two screws.
•
Remove the rear mudguard.
Lower cowl
(RS 125)
RS 125 - Tuono 125 - Euro 4 Bodywork
BODYW - 359
