Removing the throttle body
•
Remove the filter box.
•
Loosen and remove the nut and un-
hook the throttle cable.
•
Disconnect the connector.
•
Undo and remove the screw and re-
move the cable guide.
•
Loosen the clamp and remove the
throttle body.
Power supply RS 125 - Tuono 125 - Euro 4
P SUPP - 228
