Installing
•
Fit the brake disc and tone wheel in the
respective seat.
•
Fit the six fastener screws and tighten
to specified torque.
NOTE
FIRST HAND-TIGHTEN TIGHTEN ALL THE SCREWS,
THEN TIGHTEN TO THE DEFINITIVE TORQUE IN A
CROSSED PATTERN IN THE SEQUENCE A-D-B-E-C-F
CAUTION
THE BRAKE DISC FIXING SCREWS ARE THE PRE-IM-
PREGNATED VARIETY. ONCE REMOVED THEY SHOULD
BE REPLACED WITH NEW SCREWS.
CAUTION
BEFORE FITTING THE NEW SCREWS, CLEAN THE
THREADED HOLES CAREFULLY, MAKING SURE THAT
ALL TRACES OF THE OLD THREAD-LOCK SEALANT
HAVE BEEN ELIMINATED.
Front brake disc
Removal
•
- Remove the front wheel.
•
Undo and remove the six screws fas-
tening the tone wheel/brake disc.
•
Remove the tone wheel.
RS 125 - Tuono 125 - Euro 4 Braking system
BRAK SYS - 297
