Remove the clutch cover;
•
Heat the clutch cover to facilitate extraction of the water pump spindle assembly;
•
Support the clutch cover on a press
and with the specific tool "B", remove
the water pump shaft group, acting
from the external part to the internal
one.
Specific tooling
866380 tool description
•
Turn the clutch cover and acting from
the internal part to the external one with
the specific tool "C", take out the seal
ring;
Specific tooling
866380 tool description
•
Support the group of the water pump
shaft on a vice and after it is sufficiently
heated up, separate it with a punch
from the gear;
Installing
CAUTION
Cooling system RS 125 - Tuono 125 - Euro 4
COOL SYS - 314
