4-33
Loading Paper in the Multi-purpose Tray
Paper Loading and Output Tray
4
Loading Paper in the Multi-purpose Tray
The multi-purpose tray can be loaded with up to approximately 50 sheets of plain
paper (80 g/m
2
) at sizes of A4, B5, A5, Legal, Letter, Executive, Index Card,
Statement, 16K, and paper of the following custom paper sizes.
• Custom Size Paper
When loading paper in portrait orientation: Width 76.2 to 215.9 mm; Length 127.0
to 355.6 mm
When loading paper in landscape orientation (Only when UFR II Printer Driver is
used): Width 127.0 to 215.9 mm; Length 127.0 to 215.9 mm
Paper that cannot be loaded in the paper cassette such as transparencies and
envelopes can be loaded in the multi-purpose tray.
When printing from the multi-purpose tray, you need to specify the following
settings.
IMPORTANT
•
Match the setting for TRAY PAPER SIZE in the SETUP menu of the printer and that in the
printer driver
.
If they do not match, the message <PC LO
AD "size"> appears
.
In this
case, the setting value for TRAY PAPER SIZE is changed to that in the printer driver by
pressing the (Online) key, allowing you to continue printing.
•
For more details on the usable paper, see "Usable Paper," on p. 4-2.
•
For details on how to handle the multi-purpose tray, see "Precautions for Handling the
Multi-purpose Tray or Paper Cassette," on p. 4-12.
NOTE
If you are printing from an operating system on which the printer driver cannot be used,
previously specify the paper source to TRAY. (See p. 4-11)
■ Loading Paper (Other than Envelopes) (See p. 4-35)
■ Loading Envelopes (See p. 4-39)
■ Specifying the Size of the Paper in the Multi-purpose Tray (See p. 4-44)
If you changed the size of the paper in the multi-purpose tray, specify the following
settings using the control panel. You do not need to specify the settings if you did not
change the size of the paper.
The FEEDER MENU options in the SETUP menu
• TRAY PAPER SIZE = the size of the loaded paper
To Next Page
