6-37
Printing Environment Settings
6
SETUP Menu Settings
USER MAIN. Options
ADJ.START POS.
OFFSET Y(TRAY).................-5.0 to 5.0; 0.0* (mm)
OFFSET X(TRAY).................-5.0 to 5.0; 0.0* (mm)
OFFSET Y(CASS1) ..............-5.0 to 5.0; 0.0* (mm)
OFFSET X(CASS1) ..............-5.0 to 5.0; 0.0* (mm)
OFFSET Y(CASS2)*
1
...........-5.0 to 5.0; 0.0* (mm)
OFFSET X(CASS2)*
1
...........-5.0 to 5.0; 0.0* (mm)
OFFSET Y(DUP.) ..................-5.0 to 5.0; 0.0* (mm)
OFFSET X(DUP.)..................-5.0 to 5.0; 0.0* (mm)
*1 OFFSET Y(CASS2) and OFFSET X(CASS2) are displayed only when the optional paper feeder is
installed.
Specifies the printing position of the paper in the specified paper source. Adjusts
the position in the vertical direction (Y) or the horizontal direction (X) by the
specified value.
The setting values are indicated in millimeters (mm), and you can adjust the
position in 0.1 mm increments using [ ] and [ ].
If you do not adjust the printing position, specify "0.0" for this item.
OFFSET Y(DUP.) and OFFSET X(DUP.) allow you to specify the printing position
of the first page of 2-sided printing. The second page of 2-sided printing follows
the settings for each paper source.
IMPORTANT
If any part of the print image lies outside the printable area after adjusting the
printing position, the part will be missing in the print result.
NOTE
•
Each time you press [ ], the value increases in 0.1 mm increments, and each
time you press [ ], the value decreases in 0.1 mm increments.
•
You can check the adjusted printing position in PRNTPOSNPRINT (See p. 6-49) in
the UTILITY menu.
•
For adjusting the printing position, see "Adjusting the Printing Position," on p. 7-22.
•
Be aware that, when adjusting the printing position for 2-sided printing, the
orientation of the images on the reverse pages varies depending on the printing
orientation or setting for
BIND.LOCATION (See p. 6-21)
.
To Next Page
