Digi XBee 3 User Manual

Technical specifications Interface and hardware specifications
Digi XBee® 3 Cellular LTE Cat 1 AT&T Smart Modem User Guide
102
Interface and hardware specifications
The following table provides the interface and hardware specifications for the device.
Specification Value
Dimensions 2.438 x 3.294 cm (0.960 x 1.297 in)
Weight 5 g (0.18 oz)
Operating temperature
-40 to +80 °C
Antenna connector U.FL for primary and secondary antennas
Digital I/O 13 I/O lines
ADC 4 10-bit analog inputs
RF characteristics
The following table provides the RF characteristics for the device.
Specification Cellular value Bluetooth value
Modulation LTE/4G – QPSK, 16 QAM
QPSK
Transmit power 23 dBm
9 dBm
Receive sensitivity -102 dBm
-92 dBm
Over-the-air maximum data rate 10 Mb/s 2 Mb/s
Networking specifications
The following table provides the networking and carrier specifications for the device.
Specification Value
Addressing options TCP/IPand SMS
Carrier and technology AT&T LTE Cat 1
Supported bands 2, 4 and 12
Security TLS
Power requirements
The following table provides the power requirements for the device.
Specification Value
Supply voltage range 3.0 to 5.5 VDC
Extended voltage range 2.7 to 5.5 VDC
