AT commands I/O settings commands

Digi XBee® 3 Cellular LTE Cat 1 AT&T Smart Modem User Guide

203

I/O settings commands

The following AT commands are I/O settings commands.

D0 (DIO0/AD0)

Sets or displays the DIO0/AD0 configuration (pin 20).

Parameter range

0, 2 - 5

Parameter Description

0 Disabled

1 N/A

2 Analog input

3 Digital input

4 Digital output, default low

5 Digital output, default high

Default

D1 (DIO1/AD1)

Sets or displays the DIO1/AD1 configuration (pin 19).

Parameter range

0 - 6

Parameter Description

0 Disabled

SPI_ATTN

2 ADC

3 Digital input

4 Digital output, low

5 Digital output, high

6 I2C SCL

Default
