AT commands I/O settings commands

Digi XBee® 3 Cellular LTE Cat 1 AT&T Smart Modem User Guide

208

Parameter range

0, 1, 3 - 6

Parameter Description

0 Disabled

1 Fan enable. Output is low when the XBee Smart Modem is sleeping, turning an

attached fan off when the cellular component is in a power saving mode, and also

during Airplane Mode

2 Enables PWM output

3 Digital input

4 Digital output, default low

5 Digital output, default high

6 I2C SDA

7 USB direct

Default

P2 (DIO12 Configuration)

Sets or displays the DIO12 configuration (pin 4).

Parameter range

0, 1, 3 - 5

Parameter Description

0 Disabled

1 SPI_MISO

2 N/A

3 Digital input

4 Digital output, default low

5 Digital output, default high

Default

P3 (DIO13/DOUT)

Sets or displays the DIO13/DOUT configuration (pin 17).

Default Chapter2
