API frames Socket Connect Response - 0xC2

Digi XBee® 3 Cellular LTE Cat 1 AT&T Smart Modem User Guide

271

Socket Connect Response - 0xC2

Description

The device sends this frame in response to a Socket Connect (0x42) frame. The frame contains a

status regarding the initiation of the connect.

Format

The following table provides the contents of the frame. For details on frame structure, see API frame

format.

Field name Field value Data type Description

Frame type 0xC2 Byte

Frame ID Byte A reference identifier used to match status responses.

Socket ID Byte ID of the socket that will be connected.

Status Byte Status code. See the table below.

The following table shows the status codes.

Code Description

0x00 Successfully started the connection process

0x01 Invalid destination address type

0x02 Invalid parameter: address or port

0x03 Connection already in progress

0x04 Already connected

0x05 Unknown error

0x20 Invalid socket ID
