API frames AT Command Response - 0x88

Digi XBee® 3 Cellular LTE Cat 1 AT&T Smart Modem User Guide

252

AT Command Response - 0x88

Description

A device sends this frame in response to an AT Command (0x08) frame. Some commands send back

multiple frames.

Format

The following table provides the contents of the frame. For details on frame structure, see API frame

format.

Field

name

Field

value

Data

type Description

Frame

type

0x88 Byte

Frame ID Byte Identifies the data frame for the host to correlate with a subsequent

ACK. If set to 0, the device does not send a response.

command

Byte Command name: two ASCII characters that identify the AT command.

Status

## Byte 0 = OK

1 = ERROR

2 = Invalid command

3 = Invalid parameter

Parameter

value

Byte Register data in binary format. If the register was set, then this field is

not returned.
