Introduction | Accessories: HEIDENHAIN 3-D touch probes and electronic handwheels

122

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

HR electronic handwheels

Electronic handwheels facilitate moving the axis slides precisely

by hand. A wide range of traverses per handwheel revolution is

available. Apart from the HR 130 and HR 150 integral handwheels,

HEIDENHAIN also offers the HR 510, HR 520 and HR 550FS

portable handwheels.

Further information: "Traverse with electronic handwheels",

page 627

Several electronic handwheels can also be connected

simultaneously and used alternatively on controls with

the (HSCI: HEIDENHAIN Serial Controller Interface)

serial interface for control components.

Configuration is performed via the machine tool builder.
