Programming Aids | Display of NC programs

204

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

5.4 Display of NC programs

Syntax highlighting

The control displays syntax elements with various colors according

to their meaning. Programs are made more legible and clear with

color-highlighting.

Color highlighting of syntax elements

Use Color

Standard color Black

Display of comments Green

Display of numerical values Blue

Display of the block number Violet

Display of FMAX Orange

Display of the feed rate Brown

Scrollbar

Screen content can be shifted with the mouse using the scroll

bar at the right edge of the program window. In addition, the size

and position of the scrollbar indicates program length and cursor

position.
