Programming Q Parameters | String parameters

444

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Assign string parameters

Before using string variables, you must first assign the variables.

Use the DECLARE STRING command to do so.

Press the SPEC FCT key

Press the PROGRAM FUNCTIONS soft key

Press the STRING FUNCTIONS soft key

Press the DECLARE STRING soft key

Example

37 DECLARE STRING QS10 = "Workpiece"
