Programming Q Parameters | Accessing tables with SQL commands
10
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
435
SQL INSERT
Example: Transferring row number in the Q parameter
11 SQL BIND Q881 "Tab_Example.Meas_No"
12 SQL BIND Q882 "Tab_Example.Meas_X"
13 SQL BIND Q883 "Tab_Example.Meas_Y"
14 SQL BIND Q884 "Tab_Example.Meas_Z"
. . .
20 SQL Q5 "SELECT Meas_no,Meas_X,Meas_Y, Meas_Z FROM
Tab_Example"
. . .
40 SQL INSERT Q1 HANDLE Q5
SQL UPDATE creates a new row in the result set (intermediate
memory). The values of the individual cells are copied from the
bound Q parameters. The transaction is defined via the HANDLE to
be specified.
SQL INSERT takes all columns into consideration that were
specified with the SELECT instruction (SQL command SQL
EXECUTE). Table columns without corresponding SELECT
instruction (not contained in the query result) are assigned defaults
values.
Parameter No. for result (return value for the
control):
0 successful transaction
1 successful transaction
Database: SQL access ID: Define Q parameters
for the HANDLE (for identifying the transaction)
