Operating the Touchscreen | Gestures

128

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Symbol Gesture Meaning

Two-finger drag A combination of long-press and then swipe, moving

two fingers in parallel over the screen when the start-

ing point is clearly defined

Spread Two fingers long-press and move away from each

other

Pinch Two fingers move toward each other

Navigating in the table and NC programs

You can navigate in an NC program or a table as follows:

Symbol Gesture Function

Tap Mark the NC block or table line

Stop scrolling

Double tap Activate the table line

Swipe Scroll through the NC program or table
