Programming Q Parameters | Accessing tables with SQL commands
10
438
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
SQL SELECT
SQL SELECT reads a single value from a table and saves the result
in the defined Q parameter.
You can select multiple values or columns using the SQL
command SQL EXECUTE and the SELECT instruction.
Further information: "SQL EXECUTE", page 430
With SQL SELECT, there is neither a transaction nor binding
between the table columns and Q parameter. Any existing bindings
to the specified columns are not taken into consideration; only the
read-out value is copied into the parameter specified for the result.
Example: Reading and saving a value
20 SQL SELECT Q5 "SELECT Meas_X FROM Tab_Example WHERE
MEAS_NO==3"
Parameter No. for result: Q parameter for
saving the value
Database: SQL command text: Programming
SQL instruction
SELECT with the table column of the value to
be transferred
FROM with a table’s synonym or path (place
the path in single quotation marks)
WHERE with column designation, condition
and comparison value (Q parameter after : in
single quotation marks)
The result of the subsequent NC program is identical to the
application example shown previously.
Further information: "Application example", page 428
Example
0 BEGIN PGM SQL MM
1 SQL SELECT QS1800 "SELECT WMAT FROM my_table
WHERE NO==3"
Read and save a value
2 END PGM SQL MM
