HEIDENHAIN TNC 620 User Manual

Tables and Overviews | Functions of the TNC 620 and the iTNC 530 compared
20
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
817
Comparator: Cycles
Cycle TNC 620 iTNC 530
1 PECKING (recommended: Cycle 200, 203, 205)
– X
2 TAPPING (recommended: Cycle 206, 207, 208)
– X
3 SLOT MILLING (recommended: Cycle 253)
– X
4 POCKET MILLING (recommended: Cycle 251)
– X
5 CIRCULAR POCKET (recommended: Cycle 252)
– X
6 ROUGH-OUT (SL I, recommended: SL II, Cycle 22)
– X
7 DATUM SHIFT
X X
8 MIRROR IMAGE
X X
9 DWELL TIME
X X
10 ROTATION
X X
11 SCALING
X X
12 PGM CALL
X X
13 ORIENTATION
X X
14 CONTOUR GEOMETRY
X X
15 PILOT DRILLING (SL I, recommended: SL II, Cycle 21)
– X
16 CONTOUR MILLING (SL I, recommended: SL II, Cycle 24)
– X
17 RIGID TAPPING (recommended: Cycle 207, 209)
– X
18 THREAD CUTTING
X X
19 WORKING PLANE
X, option 8 X, option 8
20 CONTOUR DATA
X, option 19 X
21 PILOT DRILLING
X, option 19 X
22 ROUGH-OUT
X, option 19 X
23 FLOOR FINISHING
X, option 19 X
24 SIDE FINISHING
X, option 19 X
25 CONTOUR TRAIN
X, option 19 X
26 AXIS-SPECIFIC SCALING
X X
27 CYLINDER SURFACE
X, option 8 X, option 8
28 CYLINDER SURFACE
X, option 8 X, option 8
29 CYL SURFACE RIDGE
X, option 8 X, option 8
30 RUN CAM DATA
– X
32 TOLERANCE
X X
39 CYL. SURFACE CONTOUR
X, option 8 X, option 8
200 DRILLING
X X
201 REAMING
X, option 19 X
202 BORING
X, option 19 X
203 UNIVERSAL DRILLING
X, option 19 X
204 BACK BORING
X, option 19 X

HEIDENHAIN TNC 620 Specifications

General

Power Supply	24 V DC
Control Type	CNC
Axes	Up to 5 axes
Display	15" TFT color flat-panel display
Interfaces	Ethernet, USB
Data Transfer	Ethernet, USB
Hard Drive	SSD
Storage	SSD
