HEIDENHAIN TNC 620 User Manual

Manual Operation and Setup | Optional safety concept (functional safety FS)
16
640
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Explanation of terms
Safety-related operating modes
Description Brief description
SOM_1
Safe operating mode 1: Automatic opera-
tion, production mode
SOM_2
Safe operating mode 2: Set-up mode
SOM_3
Safe operating mode 3: Manual interven-
tion; only for qualified operators
SOM_4
Safe operating mode 4: Advanced manual
intervention, process monitoring
Safety functions
Description Brief description
SS0, SS1, SS1F,
SS2
Safe stop: safe stopping of all drives using
different methods
STO
Safe torque off: Energy supply to the motor
is interrupted. Provides protection against
unexpected start of the drives
SOS
Safe operating stop. Provides protection
against unexpected start of the drives
SLS
Safely-limited speed. Prevents the drives
from exceeding the specified speed limits
when the protective door is opened

HEIDENHAIN TNC 620 Specifications

General

Power Supply	24 V DC
Control Type	CNC
Axes	Up to 5 axes
Display	15" TFT color flat-panel display
Interfaces	Ethernet, USB
Data Transfer	Ethernet, USB
Hard Drive	SSD
Storage	SSD
