HEIDENHAIN TNC 620 User Manual

Programming Q Parameters | Preassigned Q parameters
10
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
459
Measurement results from touch probe cycles
Further information: Cycle Programming User's Manual
Measured actual values Parameter value
Angle of a straight line Q150
Center in reference axis Q151
Center in minor axis Q152
Diameter Q153
Pocket length Q154
Pocket width Q155
Length of the axis selected in the cycle Q156
Position of the centerline Q157
Angle in the A axis Q158
Angle in the B axis Q159
Coordinate of the axis selected in the cycle Q160
Measured deviation Parameter value
Center in reference axis Q161
Center in minor axis Q162
Diameter Q163
Pocket length Q164
Pocket width Q165
Measured length Q166
Position of the centerline Q167
Determined space angle Parameter value
Rotation about the A axis Q170
Rotation about the B axis Q171
Rotation about the C axis Q172
Workpiece status Parameter value
Good Q180
Rework Q181
Scrap Q182

HEIDENHAIN TNC 620 Specifications

General

Power Supply	24 V DC
Control Type	CNC
Axes	Up to 5 axes
Display	15" TFT color flat-panel display
Interfaces	Ethernet, USB
Data Transfer	Ethernet, USB
Hard Drive	SSD
Storage	SSD
