HEIDENHAIN TNC 620 User Manual

Special Functions | Working with the parallel axes U, V and W
12
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
503
Deactivating FUNCTION PARAXCOMP
After the control has been started up, the standard
configuration is effective by default.
The PARAXCOMP parallel-axis function is automatically
reset by the control with the following functions:
Selection of a program
PARAXCOMP OFF
You must deactivate the parallel-axis functions before
switching the machine kinematics.
Example
13 FUNCTION PARAXCOMP OFF
13 FUNCTION PARAXCOMP OFF W
Use the PARAXCOMP OFF function to switch off the PARAXCOMP
DISPLAY and PARAXCOMP MOVE parallel-axis functions. Proceed as
follows for the definition:
Show the soft-key row with special functions
Press the PROGRAM FUNCTIONS soft key
Select FUNCTION PARAX
Select FUNCTION PARAXCOMP
Select FUNCTION PARAXCOMP OFF. If you want
to switch off the parallel-axis functions only for
individual parallel axes, then the respective axis
must be specifically indicated.
